Dane techniczne

Light group

HOR 89

Light category

multifunction rear

Rear direction indicator

yes

Ingress protection rating

IP 68

LED light

yes

Supply voltage

12/24 V

Number plate light

yes

Cable

7×0,5 mm2; cable length 2 m

Side

universal

Reversing light

yes

Brake light

yes

Rear position light

yes

Fog light

yes

Operating temperature range

from -30°C to +50°C

LZD 2540

Multifunction rear lamp EMA

Pliki do pobrania

Cała zawartość strony (LZD 2540.zip) Multifunction-light-LZD-2540-technical-drawing-3 (Multifunction-light-LZD-2540-technical-drawing-3.pdf) Multifunction-light-LZD-2540-approval-AR (Multifunction-light-LZD-2540-approval-AR.pdf) Multifunction-light-LZD-2540-approval-L (Multifunction-light-LZD-2540-approval-L.pdf) Multifunction-light-LZD-2540-approval-2a (Multifunction-light-LZD-2540-approval-2a.pdf) Multifunction-light-LZD-2540-technical-drawing (Multifunction-light-LZD-2540-technical-drawing.pdf) Multifunction-light-LZD-2540-approval-R1-S1 (Multifunction-light-LZD-2540-approval-R1-S1.pdf) Multifunction-light-LZD-2540-technical-drawing-2 (Multifunction-light-LZD-2540-technical-drawing-2.pdf) Multifunction-light-LZD-2540-approval-F1 (Multifunction-light-LZD-2540-approval-F1.pdf) Multifunction-light-LZD-2540-approval-R10 (Multifunction-light-LZD-2540-approval-R10.pdf)
